Quick Details

  • Condition: New
  • Place of Origin: Henan, China (Mainland)
  • Brand Name: WHIR potato chips production line
  • Model Number: WHIR-PC-DY04
  • Application: potato chips production line
  • Voltage: 380V/50hz
  • Power(W): 1.1kw
  • Weight: 500kg
  • Dimension(L*W*H): 6200*2000*2000mm
  • Certification: CE potato chips production line
  • Warranty: 12months
  • After-sales Service Provided: Engineers available to service machinery overseas
  • capacity: 150kg/h
  • product type: potato chips production line
  • voltage: 380v
  • power: 1.1kw
  • dimension: 6200*2000*2000mm
  • weight: 500kg
  • product name: potato chips production line/fresh potato chips making machine
  • condition: new
  • material: full stainless steel
  • delivery: 25working days

Packaging & Delivery

Packaging Details wooden case potato chips production line
Delivery Time 25 working days upon receipt of advanced payment.







Product Description







Full automatic potato chips production line





Description of automatic potato chips production line



Automatic Potato chips production line is of low investment, low energy consumption,



small area coverage. The processing capacity are 150kg/h and 300kg/h ,we can also customize



special plants based on your requirements.





Production Flow





Potato chips production line includes a whole set of equipment.The processing flowchart



as follows:



Hoister---cleaning and peeling machine---picking and choosing machine---hoister---cutting machine---rinsing machine---blanching machine---dewatering machine---frying machine---vibration deoiling machine---deoiling machine---flavoring machine---picking machine---packing machine







Features of automatic potato chips production line



1. The hoister is used for transmitting large quantity of potatoes into the feeder.


2. The potato cleaning and peeling machine is used to wash and peel them automatically.



3. The finished potatoes are clean enough for further processing.


4. Then it is the picking line that picks the well formed ones and send them to cutting machine.



5. The blades are stainless steel and specially designed to cut them averagely.


6. The rinsing machine is used for further washing the potato slices and strips.


7. Blanching is a necessary part in processing vegetables and fruits as it can protect their natural



    flavor from being broken.


8. Dewatering is prepared for the frying part. The dewatered potato strips are low in moisture and



    easy to fry.


9. Frying is an important step. When the potato chips become golden and soft, they should be



    fished out. Just grasp the right time, neither too early nor too late.


10. The deoiling line is next step. Deoiling will make the fried food crispier and  more palatable.



11. The following is flavoring. Customers can season diversified flavors totally according to their



      own intentions.


12. By way of the conveying belt, the seasoned potato chips are packaged.


13. The whole processing line has strict demand on workers and manufacturing shop to offer



       clients assured potato chips.











Parameters of potato chips production line





ModelPower/VoltageDimension
hoister0.55kw/380v/50Hz3350*720*2250mm
cleaning and peeling machine2.75kw/380v/50Hz2800*830*1550mm
picking machine0.55kw/380v/50Hz3900*730*1100mm
hoister0.55kw/380v/50Hz1600*700*1800mm
cutting machine1.5kw/380v/50Hz1000*800*1600mm
rinsing machine1.87kw/380v/50Hz3000*1030*1350mm
blanching machine54.55kw/380v/50Hz4500*1130*1400mm
dewatering machine6.75kw/380v/50Hz4000*950*1880mm
frying machine 120kw/380v/50Hz 6200*2000*2000mm
vibration deoiling machine 1.1kw/380v/50Hz 2000*1000*1200mm
deoiling machine 18.75kw/380v/50Hz 4000*1000*2250mm
flavoring machine 1.1kw/380v/50Hz 2800*900*2300mm
picking machine 0.55kw/380v/50Hz 3700*800*1130mm
packing machine 6kw/380v/50Hz 1450*1080*2250mm









Packaging & Shipping











Finished Products
